PLW 6011 & PLW 6111

Compact dimensions, high capacity

Perfect and analysis-grade reprocessing of laboratory glassware with the new Miele Professional SlimLine lab washers.

To the products

Customer benefits

SmartLoad – flexible use of chamber space

The new SlimLine lab washers from Miele Professional excel in terms of high performance on a small footprint. And what's more, the innovative SmartLoad system enables chamber space to be used particularly efficiently.

Models from the PLW 6111 series are able to accommodate up to 3 baskets on telescopic racks. These baskets dock onto the water circulation system at 4 different heights. This allows a wide range of load height combinations, starting with using the lowest rack level only for a maximum vertical clearance of 630 mm.

Compact machine dimensions combined with large chamber capacity

• Small footprint with width of only 650 mm
• 3 levels with injector nozzles
• Vertical clearance of up to 630 mm for large vessels

Intelligent controls

• Controls with flush, uninterrupted touch glass screen
• All information visible at a glance thanks to 3.5" display
• Maximum of 40 programme slots (standard programmes and
   vacant programme slots)
• Simple and effective cleaning
• RS232 port for connecting to a printer or PC

Simple and efficient cleaning processes

• Chamber, spray arms and tank filters are made from
   high-grade stainless steel (DIN 1.4404/AISI 316L)
• Conductivity monitoring for high-level process security
• HEPA H14 fine filter for germ-free drying air
• Built-in water softener*
• Heated boiler for shorter cycle times*

Visual monitoring of chamber

• Process control thanks to full glass door
• Integrated chamber lighting
• Automatic door lock

Products

PLW 6011

• Capacity - 168 l
• Performance/cycle: 84 narrow-necked glassware or 121
   pipettes, alternatively 312 test tubes or 84 laboratory flasks
• Ergonomic loading and unloading – telescopic runners
• Flexible – 3 different level positions thanks to SmartLoad
• Have everything in view thanks to the full-glass door

PLW 6111

• Capacity - 225 l
• Performance/cycle: 126 narrow-necked glassware or 121
   pipettes, alternatively 468 test tubes or 84 laboratory flasks
• Ergonomic loading and unloading – telescopic runners
• Flexible – 4 different level positions thanks to SmartLoad
• Have everything in view thanks to the full-glass door
• High capacity – reprocessing of flasks up to 50 l

Accessoires & process chemistry

Wide range of load carriers

• Range specifically designed for laboratory use
• Maximum flexibility combined with intuitive use
• Wide range of standard and configurable loading options
• Possibility to reprocess even the smallest items of laboratory
  glassware through to very large containers (up to 50 l)

Spotless results through combination of programme cycle and process chemicals

• ProCare Lab process chemicals for optimum results
• Thorough cleaning combined with the gentlest treatment of
   materials
• Detergents and neutralising agents in various canister sizes

Downloads

Brochure and Flyer

Here you can download the current brochure with detailed information about the SlimLine laboratory glasswashers.

BrochureFlyer
